Automatic Button Cell Battery Blister Card Packing Machine

Share to:

Automatic Button Cell Battery Blister Card Packing Machine

It is ideal equipment to pack stationery, hardware, cosmetics, medicines, as well as battery, tooth brush, pens, glues, bearing, etc, which to improve the grade of products package and looking.

Cutting Frequency:	10-25/(times/min)
Adjustable Travel Range:	35-160mm
Max.Forming Area:	340*160mm
Max.Forming Depth:	38mm
Forming and Heating:	1.8kw*2
Availability:

Quantity:



Inquire Add to Basket

Model:
SP-300D
Brand:
Sonypack
Code:
8422400000
Take off weight:
1800KG
Size:
3650×2500×1850mm

This machine is suitable for the combination of industrial paperboard and plastic to pack all kinds of products.The products cover the small hardware, medical equipment, toys, batteries, electronic products, car and motorcycle accessories,cosmetics, rubber products, tableware, kitchenware and so on.

For example: drug injection, injection syringe, toy car, flashlight, spark plug, toothbrush, lipstick, facial mask, chopsticks, razor, scissors, hook, cleaning ball, bottle opener, correction fluid, ball-point pen, pencil, pencil sharpener, etc.

The assembly line consists of blister machine and rotating heat-sealing machine.

The positive and negative pressure forming, precision forming make the product more beautiful.

The automation helps save labor work and material.

It uses servo motor drive steplessly and is easy to adjust.

The separate-type design makes it convenient to transport and is free out of the elevator.

It is in low noise and high humanization.

It is easy to change the molds which can greatly improve the production efficiency.

The mold is designed according to the needs, and the automatic feeding device is optional.

Blister card Packing machine Blister Packing machine battery Blister Packing Machine Button Cell Battery Packing Machine battery Packing Machine Button Cell Packing Machine Button Cell blister Packing Machine Button Battery Blister Packing Machine Button Battery Packing Machine Automatic Battery Blister Packing Machine

Cutting Frequency		10-25/(times/min)
Adjustable Travel Range		35-160mm
Max.Forming Area		340×160mm
Max.Forming Depth		38mm( Special Machine 50mm)
Forming and Heating(Upper and Down)		1.8kw(×2)
Sealing and Heating Power		3.5kw
Total Power		380v 50Hz 10kw 480v 50Hz 10kw
Main Motor Power		1.5kw
Air Pump Volume Flow		≥0.6m³/min
Packing Materials	Roll	≤400(Diameter)×350(Width)×0.2-0.5mm(Thickness)
	Paperboard	≤350×200×0.5mm(L×W×H)
Overall Dimensions		3650×2500×1850mm(L×W×H)
Weight		1800kg

Cutting Frequency		10-25/(times/min)
Adjustable Travel Range		35-160mm
Max.Forming Area		340×160mm
Max.Forming Depth		38mm( Special Machine 50mm)
Forming and Heating(Upper and Down)		1.8kw(×2)
Sealing and Heating Power		3.5kw
Total Power		380v 50Hz 10kw 480v 50Hz 10kw
Main Motor Power		1.5kw
Air Pump Volume Flow		≥0.6m³/min
Packing Materials	Roll	≤400(Diameter)×350(Width)×0.2-0.5mm(Thickness)
	Paperboard	≤350×200×0.5mm(L×W×H)
Overall Dimensions		3650×2500×1850mm(L×W×H)
Weight		1800kg
