680T
This automatic label dismantle machine is mainly used for taking off the material after die cutting, like hangtags, label, etc. For the clothes, glass industry. With much higher efficiency, and higher production than that by hand.
It replaces manual labor, and improves product quality and enterprise benefit.
It adopts servo motor, Taiwan double guide rail and bail screw which makes accuracy less than 0.02mm.
The latest hydraulic system with inserted motor abd oil temperature cooling fan (power 3.75kw). So it has constant and big working pressure.
The complete machine is eqiupped with PLC, and with a touch screen interface in operation
Technical Parameters | |||
Model | HTQF-680 | HTQF-920 | HTQF-1080 |
Max sheeet size(x) | 680 | 920 | 1080 |
Max sheet size(z) | 460 | 680 | 780 |
Max paper pile height | 100 | 100 | 100 |
Max paper pile height | 40 | 40 | 40 |
| 400 | 550 | 650 |
Min sheet size(z) | 300 | 400 | 450 |
Bench height | 850 | 850 | 850 |
Max Take off the paper | 230x230 | 320x320 | 360x360 |
Min Take off the paper | 30x30 | 30x30 | 30x30 |
Fasterst Take off the paper | 15-22 | 15-22 | 15-22 |
Max force | 70 | 70 | 70 |
Main technical parameters | |||
Machine Model | HTQF-680 | HTQF-920 | HTQF-1080 |
Machine Width(a) | 1910 | 2400 | 2760 |
Depth Of The Machine(b) | 1480 | 1800 | 2070 |
Machine Height(C) | 1940 | 1940 | 1960 |
Machine Net Weight | 1200 | 1600 | 2000 |
Compressed Aif | 4-7 | 4-7 | 4-7 |
Gas | 2 | 2 | 2 |
Power Supply Voltage | 360V-420V,50/60HZ | 360V-420V,50/60HZ | 360V-420V,50/60HZ |
Power Consumption(maximum)A | 20 | ||
lnsurance Maximum Current A | 10 | ||
lnput Power | 3hPE | 3hPE |
|
Product features
This series of products suitable for the strip process after die cutting,Save lots of labor lmprove the quality of products,increase the efficiency of company
Main Technical Parameters
Main technical parameters
| Machine Model | QF-680 | QF-920 | QF-1080 |
| Machine Width (a) | 1910 | 2400 | 2760 |
| Depth Of The Machine(b) | 1480 | 1800 | 2070 |
| Machine Height(C) | 1940 | 1940 | 1960 |
| Machine Net Weight | 1100 | 1400 | 1650 |
| Compressed Air | 4-7 | 4-7 | 4-7 |
| Gas | 2 | 2 | 2 |
| Power Supply Voltage | 360V-420V,50/60HZ | 360V-420V,50/60HZ | 360V-420V,50/60HZ |
| Power Consumption( maximun)A | 2.0 | 2.0 | 2.0 |
| nsurance Maximum Current A | 10 | 10 | 10 |
| Input Power | 3hPE | 3hPE | 3hPE |
Pre-sales Service
Inquiry and consulting support.
Sample testing support.
View our factory.
After-sales service
Training how to install the machine, training how to use the machine.
Engineers available to service machinery overseas.
Warranty
Machines are new(or unused) and the gurantee period will be given thireteen months from shipment date. During this period, the seller will provide free maintenance and free spare parts that caused by the machine's quality, but the buyer must pay the courier cost. Parts damaged because of mishanding and consumable parts are not covered by any warranty.
All our machines have CE certificates and passed ISO9001-2008
Welcome you visit our factory to test machine by yourself!
