| Max Printing Depth: | |
|---|---|
| Cup depth: | |
| Max cup body slope: | |
| Max. Printing Speed: | |
| Cup Rim Dia.: | |
| Quantity: | |
GC- 4-180
Sonypack
8449009000
5T
6200*2500*2660mm
Main Function:
Automatic Incline type feeder,very easy to operate and suit for many kinds of cups.
Cup driver can be adjusted easily and operate fluently.
Printing cylinder separates automatic when there is no cup or double cups
The roll gearbox can be automatic adjust the distance, ensure it is no shadow of cup surface.
The printing plate has specialized punch,which can be aligned accurately, quickly and operated easily.
Replacement of mould core or cup mould is convenient and fast.
Inspect function for problem cup by corona.
Printed articles sampling inspection function when working
Automatic counting by servo motor is more accurate, more easy to collect cup
Can be drive rubber model of transfer printing automatic.
Two motors two inverter to control printing system
Main Technical Parameter:
Model | GC- 4-180 |
Max Printing Depth | 158mm |
Cup depth | 50-180mm |
Max cup body slope | 5-15degree |
Max. Printing Speed | 200-350 cups/min (shall be according to your cups) |
Cup Rim Dia. | Dia.45-180 mm |
Cup body depth | 30-180mm |
Main motor total power (two motor ) | 8 kw |
UV Curing power | 6 kw |
Total power | 16 kw |
Weight | About 5 T |
Dimension （ L*W*H ） | 6200*2500*2660mm |
sample
Automatic cup in &outlet device ( with quality inspect function)
Main Function:
Automatic Incline type feeder,very easy to operate and suit for many kinds of cups.
Cup driver can be adjusted easily and operate fluently.
Printing cylinder separates automatic when there is no cup or double cups
The roll gearbox can be automatic adjust the distance, ensure it is no shadow of cup surface.
The printing plate has specialized punch,which can be aligned accurately, quickly and operated easily.
Replacement of mould core or cup mould is convenient and fast.
Inspect function for problem cup by corona.
Printed articles sampling inspection function when working
Automatic counting by servo motor is more accurate, more easy to collect cup
Can be drive rubber model of transfer printing automatic.
Two motors two inverter to control printing system
Main Technical Parameter:
Model | GC- 4-180 |
Max Printing Depth | 158mm |
Cup depth | 50-180mm |
Max cup body slope | 5-15degree |
Max. Printing Speed | 200-350 cups/min (shall be according to your cups) |
Cup Rim Dia. | Dia.45-180 mm |
Cup body depth | 30-180mm |
Main motor total power (two motor ) | 8 kw |
UV Curing power | 6 kw |
Total power | 16 kw |
Weight | About 5 T |
Dimension （ L*W*H ） | 6200*2500*2660mm |
sample
Automatic cup in &outlet device ( with quality inspect function)
