SP-500D
Sonypack
2100Kg
5300*840*1670mm (L*W*H)
Application：
SP-500D series blister card packing machine is the new equipment which is developed by our technical departement based on the mature technology from pharmaceutical packing machinery of more than ten years, and absorbing the working principle of similar machine at home and abroad. It has the feature of advanced technology,complete function,reasonable working process, easy operation, and convenient maintenance.
Working process:
PVC unrolling→PVC heating→PVC tray forming→ Servo drawing→PVC tray punching and cutting→PVC waste rolling→PVC tray turning and locating→product feeding→automatic paper feeding→heat sealing→final product output
Application range：
This machine is suitable for the blister card packing of battery, stationery, food, medical equipment, toys, hard ward, electronics, auto parts, daily use product, cosmetic etc, such as the injector, solid gum, toy car, scissor, flashlight, battery, spark plug, lip stick, hook, shaver, pencil etc.
The main performance characteristics:
Mechanical transmission, servo motor driving, encoder control, reasonable structure,easy operation.
304 stainless steel frame, beautiful appearance, convenient for cleaning.
PLC control system, frequency speed adjust, which will help to reduce the noise and improve the running stability of the machine.
Photoelectrical control, auto detection.
Separated card feeder, which will reduce the labor force.
The whole machine is separately designed, it is convenient to delivery with lift.
To design the mould and auto feeding method according to the product shape.
Main Technical Parameters
Cutting frequency 12-25(times/min)
Maximum travel range 40-200mm
Maximum forming area 480×200mm
Standard forming depth 40mm (can be customized)
Air pressure 0.5-0.8Mpa
Air flow ≥0.5m3/min
Total power 380V 50Hz 11.8KW
Main motor power 1.5KW
Overall dimension 5800×1050×1850mm(L×W×H)
Machine weight 2100kg
Latest Electrical configuration:
ID | Name | Specification | Unit | Quantity | Remark |
1 | Servo motor | MHMD082P1U | Set | 3 | Matsushita |
MCDDT3520 | |||||
2 | Reducer | 90-WPE-010 | Only | 1 | Matsushita |
90-PLE-010 | Only | 1 | |||
3 | Touchscreen | NP5-SQ000B | Only | 1 | OMRON |
4 | Encoder | E6B2-CWZ6C 1000Line | Only | 1 | OMRON |
5 | Inverter | 3G3JZ-A4015 | Only | 1 | OMRON |
6 | PLC | CP1H-X40DT-D | Only | 1 | OMRON |
7 | PLCExpand | CP1W-CIF11 | Only | 1 | OMRON |
8 | PLCExpand | CP1W-16ET | Only | 1 | OMRON |
9 | Temperature module | CP1W-TS002 | Only | 1 | OMRON |
10 | Switching Power Supply | S8JC-Z10024C | Only | 1 | OMRON |
11 | Photoelectric switch | E3Z-T61A 2M | Only | 6 | OMRON |
12 | Intermediate relay | LY2NJ DC24V | Only | 3 | OMRON |
13 | Intermediate relay | G6B-4BND DC24V | Only | 4 | OMRON |
14 | Proximity switches | TL-Q5MC1-2 | Only | 5 | OMRON |
15 | Solid State Relay | G3NB-240B DC5-24V | Only | 3 | OMRON |
16 | Exchange | 3TS3411 220V | Only | 1 | Siemens |
17 | Empty open | 5SJ6225-7CC | Only | 1 | Siemens |
18 | Empty open | 5SJ6125-7CC | Only | 1 | Siemens |
19 | Empty open | 5SJ6332 | Only | 8 | Siemens |
20 | Push button | PB1M-10 Green | Only | 3 | Siemens |
21 | Push button | PB1M-01ZR Red | Only | 1 | Siemens |
