Full-Automatic Cosmetics Electronic Product Toothbrush Blister Sealing Packing Machine

For a toothbrush, chopsticks, bulb, tweezers, pen, pencil mask, cigarette holder, car perfume, razors, spark plugs, toy cars, lipstick, battery, bottle opener, correction tape, coat hooks, cleaning ball, scissors, needles, lollipops, chocolate, lotions, jam, honey and other related products, daily necessities tableware, stationery, toys, hardware, electronics, automobile and motorcycle parts, plastic products, cosmetics, medical equipment, food, medicine, liquid filling paper and plastic packaging industry.

• It adopts the form of positive pressure molding, feeding, heat sealing, punching, easy tearing, cutting, cutting waste, finished product conveying and so on. The structure is simple and the operation is convenient;
• 304 stainless steel shell, in line with the requirements of the pharmaceutical GMP, beautiful appearance, easy to clean;

• Frequency conversion speed control, color touch screen (HMI) and PLC programmable control system, high output, low noise, clear and simple operation, high degree of automation, more humane;
• The servo motor and the ball screw mechanism are used to realize the reciprocating motion of the mechanism;
• Using the proximity switch control PVC yingpian feeding, PVC ran out of cardboard and is not enough when the alarm buzzer prompts;
• Using the device volume plastic sheet, can save a lot of packaging materials; according to user and packaging requirements of mold design and automatic feeder.

Blanking frequency : 8-15 Times/Minute
Travel range : 40-180mm
Air pressure: 0.5-0.8Mpa
Air flow: ≥0.8m3/min
Total power supply : 380V 50HZ 9Kw
Main motor power: 2.2 Kw
PVC Maximum specification :  260×180mm(Can be designed according to user requirements)
Maximum size of paperboard: 260×180mm(Can be designed according to user requirements)
Outline dimension: 4500×800×1650mm(L×W×H)
Net weight(kg): 1500
