| Quantity: | |
|---|---|
HY-200
Sonypack
8422400000
6500
7000x1800x1900 mm
Roll fed paper bag making machine
This model is a new generation of high-speed square-bottomed paper bag machine. It has the advantages of high speed, high production efficiency and large adjustment range. It has international advanced technology and is currently crystallized in all paper bag machines at home and abroad. This machine will automatically or hydraulically feed the original color or printed web from the machine, upper side glue, barrel, cut, bottom indentation, bottom glue, bag bottom forming, finished bag, computer central control system, process by The man-machine interface touch screen display, PLC control, and the length of the paper bag by the servo motor can produce a variety of paper bags. It can produce 210 bags per minute, which greatly reduces labor costs and is an ideal partner for your business.
Machine Specifications:
| Model | 200 | 330 | 430 | 460 | 550 |
| Roll width(mm) | 280-640 | 410-990 | 510-119 | 530-1350 | 570-1350 |
| Max Unwind Diameter(mm) | 1000 | 1200 | 1200 | 1200 | 1200 |
| Substrate core diameter(mm) | ¢76 | ¢76 | ¢76 | ¢76 | ¢76 |
| Paper weight(gsm) | 50-120 | 60-150g | 70-150 | 70-150 | 80-150 |
| Bag width(mm) | 80-200 | 120-330 | 160-430 | 170-460 | 190-550 |
| Bottom width(mm) | 50-110 | 70-150 | 80-170 | 80-200 | 80-250 |
| Bag length(mm) | 170-370 | 270-600 | 270-600 | 300-700 | 330-750 |
| Speed(bags/min) | 50-120 | 80-150 | 80-130 | 70-120 | 70-120 |
| Power (KW) | 10 | 16 | 16 | 18 | 20 |
| Total Weight (KG) | 6500 | 9000 | 10000 | 13000 | 14000 |
| Machine size(m) | 7x1.8x1.9 | 12.5*2.1.×2.0 | 12.5×23×2.0 | 13.5×2.5×2.5 | 13.5×2.5×2.5 |
Control bag length through the human-machine touch screen interface
PLC programmable servo motor control system
Equipped with an accurate photocell system for printed mark tracking
Color mark error stopping system
Automatic oil lubrication system
Automatic counting system
Automatic collection syste
Why choose us
1. Use the most advanced raw materials and strictly control
2. Competitive price
3. The most powerful pre-sale, in-sale and after-sale team
Pre-sales: Professional sales staff will introduce you to the functions and uses of the products in detail, and provide you with technical services, such as factory, layout, personnel training, etc. according to the different situations of customers. Entrepreneurship budget and recommendations.
in sale: the processing flow after order update will be updated to you in real time
After-sales: Our relevant personnel will provide online video remote guidance and video operation process within 24 hours
The free warranty for the device is one year. If the equipment parts are damaged during the warranty period, the parts can be replaced free of charge. Freight is required to be paid (excluding express fee)
